Hi!, I'm glad you found the article useful, the error shown above has nothing to do with the adafruit library or hardware, the problem it's clear in the last line:

zeroDivisionError: float division by zero

that means that the code it's performing a division by zero which is not possible.

Have you changed the simplest.py file? in your code, I'm seeing lines that are not found in the original one.

Edit: I've checked the library and it says that it's' deprecated, maybe that has to do with the problem, either way, I recommend you skip that test and work with the second library I showed in the post, it's simpler and works better.

Hope this helps, let me know how you do.

Gary Vladimir Núñez López

Hi! Thanks for your answer. I just repeated the tutorial with the second library (--> Adafruit_CircuitPython_ServoKit).

The same kind of error:

Traceback (most recent call last):
  File "/home/pi/rover/Main.py", line 35, in <module>
    test.test()
  File "/home/pi/rover/Controllers/ServoController.py", line 12, in test
    kit.servo[7].angle = 175
  File "/home/pi/.local/lib/python3.7/site-packages/adafruit_servokit.py", line 147, in __getitem__
    servo = adafruit_motor.servo.Servo(self.kit._pca.channels[servo_channel])
  File "/usr/local/lib/python3.7/dist-packages/adafruit_motor/servo.py", line 89, in __init__
    super().__init__(pwm_out, min_pulse=min_pulse, max_pulse=max_pulse)
  File "/usr/local/lib/python3.7/dist-packages/adafruit_motor/servo.py", line 29, in __init__
    self.set_pulse_width_range(min_pulse, max_pulse)
  File "/usr/local/lib/python3.7/dist-packages/adafruit_motor/servo.py", line 33, in set_pulse_width_range
    self._min_duty = int((min_pulse * self._pwm_out.frequency) / 1000000 * 0xFFFF)
  File "/home/pi/.local/lib/python3.7/site-packages/adafruit_pca9685.py", line 56, in frequency
    return self._pca.frequency
  File "/home/pi/.local/lib/python3.7/site-packages/adafruit_pca9685.py", line 134, in frequency
    return self.reference_clock_speed / 4096 / self.prescale_reg
ZeroDivisionError: float division by zero

I expect you have nothing different running than the stock Raspian? What version of python do you use? Python3.10? I have Python3.7 on the Raspberry Pi, and I do not know how to upgrade it to 3.10...

Your help would be VERY appreciated!
